Aug 1, 2021 - 4 minute read - API Testing API Challenges Evil Tester

Simulation Mode

This post and video shows how to use the Simulation Mode in API Challenges.

What are the API Challenges?

Our API Challenges Application has a fully functional cloud hosted API, and a set of challenges to work through.

Overview

The API has a simulation mode, this allows you to experiment with different tools in a controlled environment.

Watch on YouTube

Patreon ad free version

Simulation Mode

The simulation mode uses hard coded data in responses, but tries to mimic some conditions.

e.g. it expects you to post a specific JSON payload or XML payload and responds ‘as if’ you sent it. But… it also checks if you sent valid json, or valid xml, and responds based on your headers e.g. returning XML if you ask for it.

The simulator is stateless and does not track your usage, making it deterministic for multiple users. Which means:

  • Entities created do not show in the ‘entities’ call, but can be retrieved by a ‘GET’
  • Entities deleted do not show in the ‘entities’ and respond to a 404, but the delete for them will return a 200… you can only delete ‘specific’ entities, other entities will respond with a forbidden request.
  • etc. there are ‘inconsistencies’ but they are logical based on the needs of a stateless simulator. Use the actual API that underpins the challenges if you want a ‘real’ API.

Try the verbs and payloads listed below as a way of making sure your tooling is setup and you understand the absolute basics about API usage and Testing.

GET /sim/entities (200)

  • Entities 1-10
  • Get all the entities in the simulator

GET /sim/entities/1 (200)

  • Return entity number 1… try any of the entities listed
  • Entities 1-8 are suitable for getting, 9 and 10 are for deletes and amendments so you may not get the response you are expecting

GET /sim/entities/404 (404)

  • Entity does not exist, receive a 404 response

POST /sim/entities (201)

  • Create an entity…note we assume you are creating with the payload below, because that is what we return. Creates an entity that is not listed in the /entities list, but it will be returned by GET to keep consistent with the location header.
  • Will create Entity with ID 11
  • Entity 11 - Get will work for this but it will not show in the entities list. It will appear in the location header
    {"name": "bob"}

POST /sim/entities/10 (200)

  • Amend an entity…note we assume you are amending to the payload below, because that is what we return. Creates an entity that is not listed in the /entities list, but it will be returned by GET to keep consistent with the location header.
  • Will amend Entity with ID 10, once you amend you can GET this item and check it has amended
  • Entity 10 - Get will show the amendment, but the list view will show the original name “entity number 10”
    {"name": "eris"}

PUT /sim/entities/id (200)

  • Amend an entity…note we assume you are amending to the payload below, because that is what we return. Creates an entity that is not listed in the /entities list, but it will be returned by GET to keep consistent with the location header.
  • Can amend Entity with ID 10, once you amend you can GET this item and check it has amended
  • Entity 10 - Get will show the amendment, but the list view will show the original name “entity number 10”
    {"name": "eris"}
  • Can also create entity with id 11
    {"name": "bob"}

DELETE /sim/entities/id (204)

  • the only entity you can delete is id 9
  • if you GET id 9 then you will find it 404’s

Other things to try:

  • Try malformed XML and JSON for POST and PUT
  • Try amending the Content-Type to XML and passing in <entity><name>bob</name></entity>
  • Try accept application/xml and application/json
  • Delete an entity listed in the /entities call is forbidden id < 9
  • POST/PUT an entity listed in the /entities call is forbidden id < 10
  • PATCH and TRACE should be 501 Unimplemented for all end endpoints
  • other /sim/* endpoints should 404

How to Use

Work through the requests in sequence to achieve a fairly logical interaction.

  • try different tooling, the only difference then will be the tool because the API is fairly forgiving and no-one else can interfere with your practice. Use it to learn the tools.
  • try different automated execution approaches. The API is simple, there are only a few requests and sequences, so use it to learn a new automated execution tool. It won’t change as you are automating, if something goes wrong then it is most likely some nuance of the tool.

This simulator is designed to make starting with API testing as simple as possible.

Insomnia Walkthrough Video

Watch on YouTube

Patreon ad free version

Postman Walkthrough Video

Watch on YouTube

Patreon ad free version

Try the simulation mode on Heroku

Learn More and Start Testing
