3 minute read - Testing Techniques

Boundary Value Analysis Explained

Jan 24, 2019

TLDR; Boundary Value Analysis is a simple technique and with additional exploration can add value in the real world.

Boundary Value Analysis (BVA) is one of the most basic test techniques that we learn.

Often taught at the same time as Equivalence Partitioning.

In this post I explain the technique and use it it find a bug in Chrome and Firefox.

Boundary Value Analysis Technique

BVA if often applied to input fields or anywhere that ranges of input are used where there is some maximum and minimum validation.

e.g. if I have an input field which accepts values from 10 to 100 then 10 would be the minimum, 100 would be the maximum.

I can model that as. a Set of Ordered sets:


{ x <= 9}{10 -> 100}{101 to infinity}

Above is a model containing 3 sets, the first set

  • all the values less than 10

The second set:

  • values from 10 to 100 inclusive

The third set

  • values greater than 100

The values on the boundaries between the sets are (9,10) and (100,101) and they are the basic values that BVA would give me when applied as a technique.

Another way to consider this is as -1,0 and +1 for the valid boundary maximum and minimum range values.

The maximum and minimum values are 10 and 100 which gives me:

  • 10 -1 = 9
  • 10 + 0 = 10
  • 10 + 1 = 11 (optional extension)
  • 100 -1 = 99 (optional extension)
  • 100 + 0 = 100
  • 100 + 1 = 101

The additional values within the same equivalence class are optional and are an extension i.e. 11 (+1 on the minimum range value) and 99 (-1 on the maximum range value).

Traditional Boundary Value Analysis Demonstrated

Real World Application of Boundary Value Analysis

In the real world we use Boundary Value Analysis as a starting point, but we also have to consider:

  • input validation
  • server side validation
  • use of the value by later processing
  • formatting and representation of values
  • assumptions in the BVA model
  • implementation

When I was looking at the sample application in the Chrome I discovered that some of my assumptions were incorrect.

Not all non-numeric characters were excluded, I could type “e”, “-”, “+”, and “.”

This led me to explore other representations of my valid boundery values, which might have caused an error in a downstream system:

  • “10.0”
  • “2e1” (which is 2 exponential 1, i.e. 2 * 10^1 = 20)
  • “100.0000000000000001” which is invalid, but reported as valid in Chrome and Firefox

This is demonstrated in the following video where the exploration around BVA found a defect in Chrome and Firefox.

Boundary Value Analysis is a Heuristic

Boundary Value Analysis is technique driven from the Heuristics:

  • errors happen at the edges

  • watch out for off by one errors

The technique concentrates on the off by one errors.

The heuristic of errors at edges is much more generic and applies to any model involving bordering.

I created a video explaining the heuristic nature of boundary value analysis on Patreon.
